Easton Axis 5mm Shafts, dz.
Description
The hands-down proven small diameter all carbon arrows. Faster, Deeper, Deadlier. - SHAFTS ONLY (NOT FLETCHED ARROWS)
Micro diameter focuses energy into a small frontal area for less friction and greater penetration.
Smaller side profile helps keep the arrow on target in crosswinds.
Offers 24% more Kinetic Energy Density than standard diameter carbon arrows for more big game stopping penetration
Seven sizes from 700 through 260
Straightness ±.003-weight and spine matched for top level accuracy.
SPECIFICATIONS
• Pre-installed X Nock
• X HIT 8-32 inserts
• Straightness: ± .003”
• High-strength carbon-composite fibers
Brass X HIT® 8-32 Break-Off Insert & Deep Six thread RPS sold separately
Size | Shaft Weight GPI |
Spine @ 28″ Span Deflection in inches |
Stock Length Inches |
RPS Point O.D. Inches |
Broadhead Adapter Ring (5 grains) | O.D. Inches |
Half Out Size |
---|---|---|---|---|---|---|---|
700 | 6.1 | 0.700 | 31.5 | 17/64 | BAR 3 | 0.245 | #1 |
600 | 7.2 | 0.600 | 30.5 | 17/64 | BAR 3 | 0.253 | #1 |
500 | 8.1 | 0.500 | 31 | 17/64 | BAR 3 | 0.256 | #1 |
400 | 9.0 | 0.400 | 31.5 | 17/64 | BAR 4 | 0.264 | #2 |
340 | 9.5 | 0.340 | 32 | 9/32 | BAR 5 | 0.267 | #2 |
300 | 10.7 | 0.300 | 32.5 | 9/32 | BAR 6 | 0.275 | #2 |
260 | 11.5 | 0.260 | 34* | 9/32 | BAR 6 | 0.280 | #2 |
